VFS 5000/7300 A5
HUIDA
VFS 5000/7300 A5 Automatic stabilo &quad bag making packaging machine
Model | External dimensions (L×W×H) mm | Type of bag | Range of bag width mm | Packaging speed bags/min | ID of reel | Max. allowable OD of reel | Compressed air requirement | Power supply |
VFS5000A5 | 2455X1230X1660 | Quad bag,bag with hole punching | Front face width: 50~190 Side face width: 50~90 Width of corner seal: 5~8 Bag length range: 100~350mm Max. width of packaging material: 520mm | 15~55 | Φ75mm | Φ450mm | 0.6MPa 350L/min | 380V 50~60Hz 3kW |
VFS7300A5 | 2550X1420X1930 | Front face width: 60~260 Side face width: 60~120 Width of side seal: 5~10 Bag length range: 100~460mm Max. width of packaging material: 730mm | 2~45 | Φ75mm | Φ450mm | 0.6MPa 350L/min | 380V 50~60Hz 3kW | |
Application:
Suitable for the quantitative packaging of a variety of irregular materials, such as snack foods (potato chips, rice crackers, candies), nuts (walnuts, pistachios, hazelnuts, etc.), frozen foods (dumplings, shrimp, frozen vegetables), and various other materials with irregular shapes such as granules, chunks, balls.
Technical features:
1. Equipped with sensor check the colour mark for bag length
2. Film pulling Centralized System
3. Film easy and connect Unit easy to change roll of film
4. Film Pulling- Servo Driven also can adopted vacuum pulling
5. Horizontal Sealing- Servo Driven
6. Vertical Sealing- Pneumatic
7.Motor driving film Roll Unwinding System
8.Sealing Temperate，film roll ,print ribbon ,film used up ,door locking all have sensor checking and alarm shows on screen
9. Have film antistatic function
10.Diamond plate forming collar
11. HMI touch screen display
12. Pneumatic Air Shaft
13. Air removal device (Pin hole system)
14.Cab make various bag types, including quad bags, gusset bags, and stabilo bags
15. Can equip with an automatic welding valve device to produce bags with vent valves according to material requirements.
